VSP DQ DRILLING RIGS AND OIL DRILLING EQUIPMENT

The booth will feature self‑developed VSP DQ series top drive complete units, compatible spare parts for all major top drive brands, and auxiliary equipment for oil drilling:

1. Self‑developed top drive complete units: DQ40B‑VSP, DQ50B‑VSP, DQ50BQ‑VSP, DQ70BS‑VSP, covering drilling depths from 2000 to 7000 metres, suitable for various onshore and offshore drilling platforms.
2. Compatible replacement parts: compatible with major top drive brands such as Varco/NOV, TESCO, CANRIG, BPM, JH Jinghong, etc., and can directly replace original factory parts.
3. Core top drive components: IBOP (internal blowout preventer), washpipe/seal assembly, top drive service loop cable, main shaft, gears/gearboxes, various adapters, hydraulic valve block assemblies, complete set of hydraulic components.
4. Supporting drilling equipment: mud pumps (complete units and full sets of spare parts); pipe handling manipulators for fingerboard, manipulators for rig floor, hydraulic elevators, slips, tongs, Christmas trees, and other drilling tool accessories.

3. Key products or new products – core products
① Self‑developed DQ series top drives (DQ40B‑VSP / DQ50B‑VSP / DQ50BQ‑VSP / DQ70BS‑VSP)
Brief description: Completely self‑designed and manufactured AC variable‑frequency top drives, rated drilling depth covering 2000‑7000m, load capacity 1350‑4500kN, featuring integrated top‑mounted hydraulic system, dual‑cylinder internal force balance structure, forced‑air‑cooled main motor, suitable for wide‑temperature operation from ‑45°C to +55°C.
Main advantages: Load and torque parameters outperform domestic counterparts at the same level; IBOP rated pressure up to 105MPa; no need for a ground hydraulic power unit, all imported hydraulic components integrated into the top drive body; modular design for easy on‑site assembly, disassembly and maintenance; can be directly matched with existing various rigs without major modifications.
② Washpipe assembly Blak Jak
One washpipe packing and two face seals are installed on the upper part of the washpipe, mainly providing static sealing for the washpipe. Four washpipe packings and face O rings are installed on the lower part to provide dynamic sealing. Internal upper and lower compression nuts pre tighten the washpipe packings to achieve sealing effect. The tungsten carbide washpipe and high quality packings ensure longer service life and better sealing performance. Compared with traditional washpipes, this high performance washpipe is lighter in overall weight and easier and faster to install. When replacing the washpipe packings, a special fixture/tool is required to disassemble the upper and lower compression nuts.
③ High reliability top drive Service Loop cable
Technical & commercial brief: Imported sheath and insulation materials; available in power, control, auxiliary and communication cable types; compatible with top drives from NOV Varco, BPM, JH Jinghong and other brands; length and connector types can be customised upon request.
Key advantages: Resistant to high/low temperatures, UV radiation, torsion and aging; factory tested with repeated bending simulation under working conditions; both domestic and imported options are available for customer choice.

④ Full-range compatible top drive spare parts (Varco/NOV/TESCO/CANRIG)
Technical & commercial brief: Covering mainstream models such as TDS‑8SA ~ TDS‑11SA, EMI EXI, DQ450DBZ, etc., including a complete set of wear parts: main shaft, IBOP, valve plates, gearboxes, washpipe assemblies, etc.
Key advantages: Dimensions, interfaces and performance are fully interchangeable with original parts; manufactured to API standards; large stock available; also provide inspection and repair services for used parts.

⑤ Mud pumps and spare parts
Technical & commercial brief: Complete 3NB and F series mud pumps, as well as full sets of wear parts including pistons, liners, valve blocks, crossheads, etc. Manufactured to API 7K standards, compatible with brands such as TSC, NOV, MH, CAMERON, LEWCO, SOUTHWEST, HH, Bomco, Zpec, etc.
Key advantages: Suitable for onshore and offshore drilling conditions; ample inventory reduces project downtime.

4. Product advantages (core competitive strengths)
1. OEM & compatible replacement parts capability: We have well‑established OEM import channels in the USA, Canada and the EU, with strict control over pricing and product quality; some products come from the same sources as original manufacturers, offering significant price advantages.
2. Strict quality control: Comply with API Spec Q1, API 7V, API 8‑C and ISO9001 quality systems; key components undergo full‑process testing including non‑destructive inspection, hydrostatic testing, mechanical property testing and material chemical analysis.
3. Delivery time: 1000m² large spare parts warehouse with abundant stock of commonly used complete units and components; fast delivery for standard parts; mature production scheduling for customised items to shorten lead times.
4. Custom manufacturing capability: We can design and produce customised top drives, cables, washpipe assemblies and adapters according to customer rig conditions, adapting to special well conditions, low‑temperature and offshore environments.
5. After‑sales service and repair capability: We have a certified team of professional top drive maintenance engineers; provide 24/7 technical support; can carry out major overhauls and on‑site maintenance offshore and on platforms; provide warranty services for complete units and components; long warranty periods for main motors and main shafts.
6. International project experience: Products sold to more than 30 countries including the Middle East, Russia, Africa, India, etc.; familiar with international HSE, H₂S protection and other operational standards.

5. Certificates and qualifications
1. Management system certifications: ISO 9001:2015 Quality Management System; Environmental Management System; Occupational Health and Safety Management System.
2. API: Product design, manufacturing and inspection comply with API Spec Q1, API 7‑1, API 8‑C petroleum equipment specifications.
3. Product quality documentation: Certificate of Conformance (COC), hydrostatic test reports, material test reports, ultrasonic inspection reports, mechanical property test reports – full set available for each unit.
4. Patents: Multiple utility model patents covering washpipe assemblies, top drive‑related structures and other core components.
